HDPLEX 500W HiFi DC-ATX

Technical Specifications

Wattage: 500W (600W Peak) >94% DC-DC Efficiency

Feature:

High Voltage Endurance SANYO and Fujitsu Solid State Capacitors

Two PCIExpress Dual 6+2PIN Output support high wattage application

12V-48V wide range voltage input support, 6 layer 2oz copper PCB

Germany Würth Elektronik High Current Inductance, Smooth Response Curve for Peak Load

Infineon MOSFET, TI Control Chip, WIMA Audio Grade Capacitor

Dual Heatsink for MOSFET and PCB, Fanless Operation

Support 7.4x5.0mm w/center PIN (Ground) DC Input

Support Silverstone ATX Modular Cable Set and NFC Skywire ATX Cable 2.0

Specially Designed 7.4x5.0mm Screw-Lock Female DC Jack for Easy Mounting

Modular ATX output.

Operating Temperature: -10C - 70C

Safety: Overvoltage protection, Overload protection,Overcurrent protection, short circuit protection,UVP Protection

Certification: RoHS (HTT141103075R), FCC(HTT141103075F),CE (HTT141103075E),EN 61003-3-2:2006+A1:2009+A2:2009,EN 61000-3-3:2008. PDF

Dimension(without cable) :160(L) x 52 (W) x 31 (H) mm

3D Engineer File Download:STEP Format

Mouting hole spacing: 122.3mm*43.3mm

Input Voltage: 12V-48VDC

Input Connector: 7.4x5.0mm w/center PIN (Ground) and Molex 8PIN

Key Specification:

Output Voltage

Max DC Current

Full Load DC Current

Output Voltage Tolerance

Ripple Noise (mVp-p,MAX)

---

+3.3V	10A	8A	1%	10mV
+5V	10A	8A	1%	10mV
+12V	55A	45A	1%	10mV
+5VSB	2A	1.5A	3%	10mV

Connector: ATX 24PIN-24PIN Cable (21cm) x 1,8-4+4PIN Power cable for CPU (45cm) x 1, Dual 8PIN (6+2 Type Dual Head) Power Cable for PCIE device x 2, 4PIN -SATA Powerx4 (45cm), 7.4x5.0mm DC Input to Molex Male 8PIN Cable (45cm)

HDPLEX Hi-Fi 500W DC-ATX Power Supply I/O Diagram

24PIN ATX Connector
Molex PART NUMBER: 462071024 SERIES NUMBER: 46207
https://www.molex.com/en-us/products/part-detail/462071024


4PIN SATA Connector
Molex PART NUMBER: 462071004
SERIES NUMBER: 46207
https://www.molex.com/en-us/products/part-detail/462071004

8PIN CPU EPS Connector
Molex PART NUMBER: 462071008
SERIES NUMBER: 46207
https://www.molex.com/en-us/products/part-detail/462071008

8PIN Red PCIE Connector
This part does not have a Molex part number.
The closest Molex Connector would be this but it is not vertical.
Molex PART NUMBER: 455860005 SERIES NUMBER: 45586
https://www.molex.com/en-us/products/part-detail/455860005
HDPLEX part number is CS-1150-08BRT(0091) CAD drawing for this PCIE PCB RED Header download here.

8PIN DC Input Connector
Molex PART NUMBER: 462071008
SERIES NUMBER: 46207
https://www.molex.com/en-us/products/part-detail/462071008

HDPLEX 400W HiFi DC-ATX 2.1 Diagram（Discontinued）

HDPLEX 400W HiFi DC-ATX 2.0 Diagram（Discontinued）

HDPLEX 400W HiFi DC-ATX 1.X Diagram（Discontinued）

HDPLEX 300W HiFi DC-ATX Diagram （Discontinued）

HDPLEX 250W HiFi DC-ATX Diagram （Discontinued）

Package Content

1 x HDPLEX 500W DC-ATX Power Supply (12V-48V wide range voltage)

1 x 24PIN -20+4PIN ATX Cable (40cm) Black Color


1x 8PIN - 4+4PIN Cable for CPU EPS Power (45cm) Black Color

1x 8PIN - Dual 6+2PIN Cable PCIExpress (45cm) Black Color

1 x 4PIN-4xSATA Power (45cm) Black Color


1 x 7.4x5.0mm with Center PIN(Ground) Self-Lock DC Input to 8PIN Molex (45cm) Black Color with M12 Mounting Ring (Adapter Plate is not included)
